Data center Munich East
highest availability and energy efficiency

Colocation in Munich

    In mid-2017, the highly modern data center was opened in Munich Aschheim. The high security data center has already been awarded the German Data Center Award. This was awarded in 2016 in the category “Newly built energy- and resource-efficient data centers”.

    Thus, our new data center is the best prerequisite for a highly secure and available housing of your IT in Munich! In addition to this, noris network also calls its own data centers in Munich and Nuremberg. Thanks to their direct connection to the noris’s own backbone, maximum redundancy can be offered.

    In all these data centers, we offer various colocation possibilities. Please contact us and we will be pleased to advise you!

    Our data center MUC5 is a DE-CIX Enabled Site. This enables us to offer you almost unlimited bandwidth with minimum latency and shortest deployment time.

    Brochure

    Data center Munich east



    One of the 10 largest data centers in Germany

    With a total area of 11,000 square meters and an IT area of 8700 square meters, our data center in Munich East is now one of the 10 largest data centers in Germany after the expansion in 2019. In MUC5, more servers per area are possible with 60 U rack. In addition, our modern Kyoto-Cooling technology cools in an environmentally friendly and energy-efficient manner, which decreases 70% energy consumption for cooling and operation.


    The highlights of the data center at a glance

      Power supply

      • ≥ 99.999 % p. a. availability of the power supply
      • AlwaysOn technology for redundant UPS supply (A- and B-feed)
      • Emergency power supply via Diesel generators with fuel storage for at least 72 hours under full load
      • Fuel storage refillable during operation (refilling before reaching minimum level guaranteed by 24/7 contract)
      • Redundant link to energy supplier
      • 100 % usage of regenerative energy

      Air conditioning

      • Air conditioning via KyotoCooling® (allows cooling without the energy consumption of conventional compressors more than 90 % of the time)
      • ≥ 99.999 % p. a. availability of the air conditioning system
      • Separation of cold and warm areas via housing and warm air separation in double ceiling

      Network connection

      • ≥ 99.99 % p. a. availability of the backbone
      • Multi-redundant, carrier-neutral Internet connection
      • Total capacity of the Internet connection 48 Tbps
      • Connections via layer 1 (DWDM/CWDM), layer 2 (Ethernet/Fibre Channel) or layer 3 (IP/MPLS) from 100 Mbps up to 500 Gbps
      • Redundant links to all important peering points
      • DE-CIX Enabled Site (all DE-CIX services available on site)
      • Geo- and maintenance-redundant DDI connection (Double Direct Interconnect) to Nuremberg South with up to 1.99 ms latency time

      Fire protection

      • Full-coverage fire alarm and early fire detection system with direct alarm forwarding to local fire department
      • Zone-selective fire extinction based on nitrogen inertization (N2) and additional oxygen reduction via OxyReduct®
      • Use of non-flammable or flame retardant materials
      • Structural measures according to fire resistance class F90

      Security

      • Video surveillance with archiving
      • On-site 24/7 security service
      • Biometric 24/7 access control via transponder card
      • Room-in-room concept separates IT areas from outer walls
      • Perimeter protection with security fencing and turnstile
      • Rack surveillance with powerful monitoring systems
      • Separate cages within the data center with own protection, access control and intrusion detection system available

      Support

      • Phone support with 24/7 emergency hotline
      • Process oriented working methods with ticketing system
      • 3-level support concept
      • Own technical staff on site

      Transport connection

      • Sufficient parking space on noris network‘s own parking lot
      • Ground-level delivery area; loading ramp available
      • Accessibility with public transport via S2 from Munich
      • Distance to airport: 27 km (approx. 23 minutes)
      • Distance to autobahn: 1 km (A99, junction Kirchheim/Aschheim)

      Further features

      • Certifications, testing and awards:
        • ISO/IEC 27001: Information security management system
        • ISO 27001: Certification on the basis of basic IT protection
        • ISO/IEC 20000-1: Service management system
        • ISO 9001: Quality management system
        • EN 50600: Construction and operation of secure data centers
        • VdS 3406: Object-specific safety management system
        • PCI DSS: Payment Card Industry Data Security Standard
        • ISAE 3402 Type II: Internal control system based on COBIT 5
        • „Deutscher Rechenzentrumspreis 2012“
      • Walkable double ceiling instead of double floor
      • Modular concept with patented combined energy & cooling cells
      • Up to 24 kVA for all racks in the data center (high-density racks)
      • Racks used: 60 rack units x 600 / 800 mm x 1200 mm
      • Size of part racks: 12 or 28 rack units

      Europe’s new standard!

      In Munich Aschheim you’ll find the new standard for data centers: München Ost! With this data center, we have replaced our existing hobbyhorse, the still extremely modern data center Nürnberg Süd. Even more efficient, even more modular and, above all, even safer. All the details that make the data center the superlative that it is, can be seen in the following video:

      YouTube

      Mit dem Laden des Videos akzeptieren Sie die Datenschutzerklärung von YouTube.
      Mehr erfahren

      Video laden

      360° tour of our data center in Munich east

      Join the virtual tour through noris network’s data center Munich East (360° video):

      YouTube

      Mit dem Laden des Videos akzeptieren Sie die Datenschutzerklärung von YouTube.
      Mehr erfahren

      Video laden

      Let’s Rock IT

      noris network is known for its innovations. We have also taken an innovative path in the presentation of the data center München Ost. The following musical video shows you how all the components of the data center play harmoniously:

      YouTube

      Mit dem Laden des Videos akzeptieren Sie die Datenschutzerklärung von YouTube.
      Mehr erfahren

      Video laden
